Name: Al-Mg-Mn Alloy AA3004 Coloured Aluminium Sheet For Curved Curtain Wall
Brand: Qingdao Jero Steel Co., Ltd.
SKU: JC26
Price: 3,150.00 USD
Availability: InStock

Home > Products > Prepainted Aluminum Coil >

Al-Mg-Mn Alloy AA3004 Coloured Aluminium Sheet For Curved Curtain Wall

AA3004 Coloured Aluminium Sheet

Curved Curtain Wall Aluminium Sheet

Al-Mg-Mn Alloy Aluminium Sheet

Place of Origin:

CHINA

Brand Name:

JERO

Certification:

SONCAP SGS CNCA CE QM

Model Number:

JC26

Chat Now

Request A Quote

Product Details

Type:

Painted Aluminum Coil

Alloy:

3004

Surface:

Bright

Coating:

PVDF

Front Coating:

20-25 Microns

Back Coating:

5+10 Microns

Application:

Curtain Wall

Highlight:

AA3004 Coloured Aluminium Sheet

Curved Curtain Wall Aluminium Sheet

Al-Mg-Mn Alloy Aluminium Sheet

Payment & Shipping Terms

Minimum Order Quantity

7 tons

Price

3100-3200USD/TON

Packaging Details

Seaworthy Standard Export Package

Delivery Time

18-25 working days

Payment Terms

L/C,T/T,Western Union,MoneyGram

Supply Ability

5,000 TONS PER MONTH

AA5052 1.5MM PVDF Advertising Board Coated Signage Aluminum Coil

Chat Now

2700mm Super Wide Coated Aluminum Coil Extra Wide Coated Aluminum Material

Chat Now

1050 / 3003 1.0mm Thickness Prepainted Aluminium Coil For Ceiling

Chat Now

3003 H24 Pattern Color Coated Aluminium Coil For Curtain Wall

Chat Now

86-0532-8787-6524

sales@jero-steel.com

86-0532-8787-6520

Chat Now

Product Description

Al-Mg-Mn Alloy AA3004 Coloured Aluminium Sheet For Curved Curtain Wall

AA3004 series alloy demonstrates moderate-to-high mechanical strength with outstanding corrosion resistance, particularly against atmospheric conditions. It performs exceptionally well in humid and saline environments. The material offers excellent processing characteristics including cold-forming capability, weldability, and surface treatment adaptability.

Primary Applications

Curtain walls (weather-resistant, UV-proof)
Roofing systems (lightweight, corrosion-resistant)
Architectural decoration (versatile colors/finishes, easy fabrication)

Standard Specifications

Parameter	Specification	Notes
Thickness	1.5-3.0mm	Thinner (<1.5mm) may deform; thicker (>3.0mm) complicates complex shaping
Temper	H34/H44	H34 (half-hard): balances strength/formability; H44: better corrosion resistance
Surface Finish	PVDF fluorocarbon coating (2-coat system)	Must meet ASTM D7863 for 25+ year color retention
Elongation	≥10% (H34 temper)	Ensures crack-free cold bending for complex curves

Key Characteristics of 3004 Aluminum Coil

Mechanical Properties

Tensile strength: 180-240 MPa (H34 temper reaches ≥240 MPa)
Elongation: ≥8% (H34), excellent for stamping and forming

Corrosion Resistance

Mn and Mg elements enhance atmospheric/rain corrosion resistance

Formability

Excellent bendability and deep-drawing capability for complex facade shapes

Performance Advantages for Double-Curved Facades

Formability
High ductility (Mn/Mg alloying) enables cold bending for radii ≥1.5m (requires specialized roll-forming equipment).

Lightweight & Cost-Effective
1/3 the weight of glass facades, reducing structural costs with 30% faster installation.

Aesthetic Flexibility
Custom PVDF colors (metallic, woodgrain effects) with UV resistance (ΔE<3 after 15 years)

Weather Resistance
Stable performance across -40℃ to 80℃ with no cracking/deformation

Cost Efficiency
Lower lifecycle cost vs stainless steel/zinc; minimal maintenance (cleaning only)

Comparison with Other Curved Facade Materials

Material	Minimum Curve Radius	Weathering	Maintenance
3004 Aluminum	≥1.5m	Excellent (PVDF)	Low (self-cleaning)
Stainless Steel	≥3m	Outstanding	Moderate (smudging)

Notable Project Applications

Skyscrapers: Shanghai World Financial Center (decorative elements)
Airports: Beijing Daxing Airport (curved sunshades)
Commercial Complexes: Parametric facade systems

Company Advantages

Advanced Equipment

German SMS Group fully automated coating lines with ±0.01mm thickness precision, Line Speed: 120m/min (20% faster than industry average)
MES system enables real-time production monitoring with ≥99.3% product qualification rate
Multi-spectral imaging detects micro-defects as small as 0.02mm² with 99.8% recognition accuracy

Technology Patents

Anti-Static Color Aluminum Coil and Continuous Production System

Chromium-Free Passivation Solution for Color-Coated Aluminum Coils and Preparation Method

Production Process for High Solar-Reflectance Color Aluminum Coils

Method for Preparing 3D Wood Grain Aluminum Coil Based on Nanoimprint Technology

Low-Temperature Curing Technology
