Place of Origin:
CHINA
Brand Name:
JERO
Certification:
CE ISO IATF 16949 IRIS EN 45545
Model Number:
JA8
| Type | Aluminum sheet |
|---|---|
| Alloy | 5454 |
| Temper | H32 |
| Size | 1/4"x96"x96" |
| Surface | PVC film protection |
| Usage | Tank trailer |
| Automobile | IATF 16949 |
|---|---|
| Railway Transportation | IRIS ISO/TS22163 EN45545 |
| Marine | ABS CCS DNV LR NK KR |
| Aerospace | NADCAP AMS AS9100D |
| Military | GJB |
| Laboratory | CNAS |
| Code | Equipment | Brand |
|---|---|---|
| a | Aluminum ingot melting furnace | GAUTSCHI (Switzerland) |
| b | 2800mm width single stand cold rolling mill | SMS (Germany) |
| c | 4 continuous hot rolling mills | SMS (Germany) |
| d | Heavy crop and dividing shear | SMS (Germany) |
| e | Coil material annealing furnace | SMS (Germany) |
| f | All automatic three-dimensional elevated warehouse | Dematic (USA) |
| Alloy & Temper | Thickness | Tensile Strengths - ksi | Yield | Elongation % min in 2in or 4D |
|---|---|---|---|---|
| 5454-H32 | .009-.012 | 31-37 | 25-25 | 4 |
| .013-.019 | 31-37 | 25-25 | 5 | |
| .020-.031 | 31-37 | 25-25 | 6 | |
| .032-.050 | 31-37 | 25-25 | 8 | |
| .051-.113 | 31-37 | 25-25 | 10 | |
| .114-.161 | 31-37 | 25-25 | 12 | |
| .162-.249 | 31-37 | 25-25 | 14 | |
| .250-.499 | 31-37 | 25-25 | 16 |
