Name: Corrosion Resistant 5005 Aluminum Alloy Plate 1mm-12mm For Construction Material
Brand: Qingdao Jero Steel Co., Ltd.
SKU: JA74
Price: 3,000.00 USD
Availability: InStock

Home > Products > Aluminum Alloy Sheet >

Corrosion Resistant 5005 Aluminum Alloy Plate 1mm-12mm For Construction Material

Corrosion Resistant Aluminum Sheet 1mm

Aluminum Alloy Plate 1mm

Aluminum Alloy Plate 12mm

Place of Origin:

CHINA

Brand Name:

JERO

Certification:

IATF 16949 IRIS EN 45545 ABS

Model Number:

JA74

Chat Now

Request A Quote

Product Details

Type:

Aluminum Plate

Alloy:

5005

Temper:

O/H12/H14/H32/H34

Thickness:

1-12mm

Application:

Construction Material

Trade Terms:

FOB,CIF,CNF,EXW

Highlight:

Corrosion Resistant Aluminum Sheet 1mm

Aluminum Alloy Plate 1mm

Aluminum Alloy Plate 12mm

Payment & Shipping Terms

Minimum Order Quantity

7 TONS

Price

2800-3200USD/TON

Packaging Details

STANDARD EXPORT PACKAGES

Delivery Time

25-30 WORKING DAYS

Payment Terms

L/C,T/T,Western Union

Supply Ability

2,900 TONS PER MONTH

5454 H32 6.35mm Thickness Aluminum Alloy Sheet In Cylindrical Tank Trailer

Chat Now

Prime Quality 6xxx Series 6063 T6 Aluminum Alloy Sheet Medium Strength

Chat Now

6xxx Series 6082 Aluminum Alloy Sheet 6mm Thick

Chat Now

6000 Series 6062 T6 Aluminium Alloy Sheet Metal 6mm Chinese supplier

Chat Now

86-0532-8787-6524

sales@jero-steel.com

86-0532-8787-6520

Chat Now

Product Description

Corrosion Resistant 5005 Aluminum Alloy Plate

Available in thickness range of 1mm-12mm for construction material applications

Product Overview

5005 aluminum alloy is a medium-magnesium content (0.5-1.1%) non-heat-treatable 5xxx series alloy, offering excellent corrosion resistance, good formability, and weldability. Its low-copper composition makes it particularly suitable for humid or chemical environments, while maintaining superior surface treatment capabilities including anodizing.

Material Properties

Chemical Composition

Primary alloying element: Magnesium (Mg, 0.5-1.1%), with trace manganese (Mn ≤0.2%). Low copper (Cu ≤0.2%) and iron (Fe ≤0.7%), ensuring excellent corrosion resistance.

Mechanical Properties (H32 Temper Example)

Tensile strength: 145-185 MPa
Yield strength: ≥115 MPa
Elongation: ≥5%

Physical Characteristics

Density: 2.7 g/cm³ (similar to pure aluminum)
Conductivity: ~50% of pure aluminum (good for electrical/thermal applications)

Corrosion Resistance

Outstanding performance in marine and industrial environments due to low copper content.

Available Tempers

Temper	Treatment Process	Characteristics & Applications
O	Annealed	Softest state; suited for deep forming
H12	Partially hardened (~25% CW)	Balanced strength/formability (general sheet metal)
H14	Half-hard (~50% CW)	Moderate strength (architectural panels)
H32	Stabilized (H22 + low-temp anneal)	Stress-corrosion resistant (outdoor use)
H34	Hard (~75% CW)	Higher-strength parts (e.g., vehicle trim)

Key Advantages

Superior Corrosion Resistance: Outperforms copper-containing alloys (e.g., 2xxx/7xxx) in humid/chemical environments.

Excellent Formability: Easily stamped, bent, or deep-drawn (O or H2x tempers).

Surface Treatment Compatibility: Anodizes uniformly, ideal for decorative uses (e.g., architectural interiors).

Weldability: Compatible with TIG/MIG welding; minimal strength loss post-welding.

Primary Applications

Architecture: Roofing/wall cladding (weather-resistant), ceilings, curtain walls (anodized for aesthetics)
Transportation: Marine interiors (saltwater-resistant), truck liners
Appliances & Electronics: Refrigerator/AC panels, electronics enclosures
Packaging: Food containers, caps (non-toxic + corrosion-resistant)

Manufacturing Capabilities

We operate with full sets of imported vertical intelligent storage and logistic management systems, and finishing lines which fulfill all requirements for various kinds of aluminum plate, sheet and strip products.

Quality Certifications

Our comprehensive quality management system includes ISO9001:2015, ISO14001:2015, ISO45001:2018, IATF16949:2016, AS9100D, ISO/TS22163:2017, and approvals from National Classification Societies including ABS, CCS, DNVGL, LR, NK, KR.

Environmental Responsibility

We prioritize environmental protection with pulse-type bag dedust system from NEDERMAN Germany, ensuring emission indexes of main exhaust substances and particles are lower than national criteria.

Advanced Manufacturing Equipment

Code	Name	Brand
1	Aluminum ingot melting furnace	GAUTSCHI (Switzerland)
2	2800mm width single stand cold rolling mill	SMS Group (Germany)
3	4 continuous hot rolling mills	SMS Group (Germany)
4	All automatic three-dimensional elevated warehouse	Dematic (USA)
