Place of Origin:
HENAN, CHINA
Brand Name:
JERO
Certification:
IATF 16949 IRIS ABS NADCAP AS9100D ISO
Model Number:
JA43
3104 aluminum plate, also known as 3104 aluminum magnesium manganese alloy, is a 3000 series anti-rust aluminum plate alloy primarily composed of magnesium and manganese elements. This material has become the dominant choice for beverage can bodies due to its optimal balance between strength and formability.
Can Body Applications:
H19 (Extra Hard) - Most Common:
H38 - Alternative for Thinner Designs:
Provides balanced strength and formability for specialized applications.
High Strength and Rigidity: Tensile strength reaches high values in standard testing, ensuring can bodies maintain shape and integrity under internal pressure and external impact during transport.
Excellent Corrosion Resistance: Natural oxidation layer provides superior resistance to acidic and alkaline substances, preventing product deterioration and extending shelf life.
Manufacturing Compatibility: Seamlessly integrates with existing can production lines while delivering consistent surface quality for superior coating adhesion.
Superior Material Properties: Optimal balance between strength and formability maintains structural integrity while allowing ultra-thin can walls.
| Property | 3104 | 3004 |
|---|---|---|
| Strength | Higher (H19 yield ≥310MPa) | Slightly lower (H19 yield ~270-290MPa) |
| Formability | Superior deep-drawing capability (earing <3%) | Better for complex stamping (e.g., end curling) |
| Microstructure | Higher Mn content, controlled texture | More uniform grain structure |
| Typical Thickness | Body: 0.10-0.29mm | End/Lid: 0.20-0.23mm |
| Recyclability | Higher recycled content (>80%) | Slightly lower (~70%) |
Technological & Production Strengths:
| Code | Name | Brand |
|---|---|---|
| A | Aluminum ingot melting furnace | GAUTSCHI (Switzerland) |
| B | 4 continuous hot rolling mills | SMS Group (Germany) |
| C | 2800mm width single stand cold rolling mill | SMS Group (Germany) |
| D | All automatic three-dimensional elevated warehouse | Dematic (USA) |
