Place of Origin:
CHINA
Brand Name:
JERO
Certification:
CE ISO IATF16949 IRIS
Model Number:
JA4
Chinese Supply 5052 Aluminium Alloy 5 x 10 aluminum sheet designed specifically for the automotive industry. This 5000 series alloy is an Al-Mg composition offering high strength, excellent plasticity, superior fatigue resistance, and outstanding corrosion resistance.
5052 aluminum alloy is renowned for its exceptional weldability, formability, strength, durability, and thermal conductivity properties.
| Alloy & Temper | Thickness | Tensile Strengths - ksi | ULTIMATE | YIELD | Elongation % min in 2in or 4D |
|---|---|---|---|---|---|
| 5052-H32 | .008-.012 | Min | 28 | 25 | 5 |
| .014-.019 | Min | 28 | 25 | 7 | |
| .020-.031 | Min | 28 | 25 | 8 | |
| .032-.050 | Min | 28 | 25 | 10 | |
| .051-.113 | Min | 28 | 25 | 11 | |
| .115-.161 | Min | 28 | 25 | 12 | |
| .162-.249 | Min | 28 | 25 | 14 |
5052 aluminium sheet contains chromium, which functions similarly to manganese by improving resistance to stress corrosion cracking, enhancing base metal and weld strength, and reducing welding crack tendencies.
We utilize world-advanced production equipment to ensure superior product quality through optimized slab quality, advanced machinery, and refined processes.
| Code | Name | Brand |
|---|---|---|
| a | aluminium ignot melting furnace | GAUTSCHI (Switzerland) |
| b | 2800mm width single stand cold rolling mill | SMS Group (Germany) |
| c | 4 continuous hot rolling mill | SMS Group (Germany) |
| d | heavy crop and dividing shear | SMS Group (Germany) |
| e | coil material annealing furnace | SMS Group (Germany) |
| f | all automatic three-dimensional elevated warehouse | Dematic (USA) |
