Place of Origin:
CHINA
Brand Name:
JERO
Certification:
IATF 16949 IRIS CE ABS DNV
Model Number:
JA53
5083 aluminum sheet belongs to the Al-Mg series alloy family and represents the highest strength corrosion-resistant alloy among practical non-heat-treated alloys. This material is particularly suitable for welding structures and offers exceptional resistance to seawater along with excellent low-temperature characteristics.
5083 aluminum (preferred tempers H116/H321) is the material of choice for metro flooring due to its lightweight properties, high strength, and lifecycle economy.
| Temper | Processing | Mechanical Properties | Applications |
|---|---|---|---|
| H111 | Hot-rolled + annealed | Tensile ≥270 MPa, Elong. ≥12% | Complex-shaped floor components |
| H112 | Hot-rolled + natural aging | Tensile ≥275 MPa, Yield ≥125 MPa | Standard flat panels (cost-effective) |
| H116 | Special stabilization | Tensile ≥290 MPa, Yield ≥215 MPa | High-traffic areas (wear-resistant) |
| H321 | TMCP treatment | Tensile ≥310 MPa, Yield ≥230 MPa | High-strength zones (articulated sections) |
| Alloy | Pros | Cons | Typical Uses |
|---|---|---|---|
| 5083 | Best corrosion resistance, weldable | Not heat-treatable | Tankers, ships, chemical tanks |
| 6061-T6 | Higher strength (310 MPa) | Poor corrosion resistance, requires pre-heat welding | Structural frames, non-corrosive parts |
| 5052 | Lower cost, excellent formability | Lower strength (210 MPa) | Lightweight covers, interior panels |
5083-H111 one-piece curved flooring (60% fewer seams)
5083-H116 flooring (3.0 mm), 1.8-ton weight reduction per train
Surface: Anodized + anti-slip granules (friction coefficient ≥0.8)
5083-H321 honeycomb sandwich panels (1.5 mm face + 15 mm core)
We operate comprehensive imported vertical intelligent storage and logistic management systems with finishing lines that meet all requirements for various aluminum plate, sheet, and strip products.
Our company has established outstanding management and complete quality control systems based on rich industry experience, holding multiple quality management certifications including:
ISO9001:2015 ISO14001:2015 ISO45001:2018 IATF16949:2016 AS9100D ISO/TS22163:2017We have passed certification from National Classification Societies including ABS, CCS, DNVGL, LR, NK, and KR.
We prioritize social responsibility and consider environmental protection as a main task for long-term development. Our facility features a pulse-type bag dedust system from NEDERMAN Germany, with emission indices of main exhaust substances and particles lower than national criteria.
| Code | Name | Brand |
|---|---|---|
| 1 | Aluminum ingot melting furnace | GAUTSCHI (Switzerland) |
| 2 | 2800mm width single stand cold rolling mill | SMS Group (Germany) |
| 3 | 4 continuous hot rolling mills | SMS Group (Germany) |
| 4 | All automatic three-dimensional elevated warehouse | Dematic (USA) |
