Name: ASTM B209 AA5454 Mirror Finish Aluminium Sheet Plate For Liquid Tankers
Brand: Qingdao Jero Steel Co., Ltd.
SKU: JA36
Price: 3,000.00 USD
Availability: InStock

Home > Products > Aluminum Alloy Plate >

ASTM B209 AA5454 Mirror Finish Aluminium Sheet Plate For Liquid Tankers

ASTM B209 Mirror Polished Aluminium Sheet

Mirror Finish Aluminium Sheet Plate

5454 Mirror Finish Aluminum Plate

Place of Origin:

CHINA

Brand Name:

JERO

Certification:

CE ISO IATF16949 IRIS EN45545

Model Number:

JA36

Chat Now

Request A Quote

Product Details

Type:

Aluminum Plate

Alloy:

5454

Temper:

H32

Size:

1 / 4"x96"x96"

Surface:

PVC Film Protection

Application:

Tank Trailer

Highlight:

ASTM B209 Mirror Polished Aluminium Sheet

Mirror Finish Aluminium Sheet Plate

5454 Mirror Finish Aluminum Plate

Payment & Shipping Terms

Minimum Order Quantity

8 TONS

Price

2800-3200USD/TON

Packaging Details

3 LAYERS STANDARD EXPORT PACKAGE

Delivery Time

25-45 DAYS

Payment Terms

L/C,T/T,Western Union,MoneyGram

Supply Ability

2000 TONS PER MONTH

6000 Grade EN AW 6082 Aluminum Plate 6xxx Aluminum Plate For Pressure Vessels

Chat Now

5052 H32 Aluminum Plate 4mm-260mm Automotive Aluminum Sheet

Chat Now

Marine Grade High Strength Aluminium Sheet 48 Inch 5083 Aluminum Plate Shipbuilding Sheet

Chat Now

5000 Grade 5754 Plain Aluminum Sheet Plate , Mill Finish Aluminum Sheet For Industry

Chat Now

86-0532-8787-6524

sales@jero-steel.com

86-0532-8787-6520

Chat Now

Product Description

ASTM B209 AA5454 Mirror Finish Aluminum Sheet Plate for Liquid Tankers

ASTM B209 AA5454 mirror-finished aluminum plates provide an optimal balance of lightweight construction, corrosion resistance, and hygienic properties, making them ideal for food and chemical tanker applications. For detailed technical parameters including fatigue life and welding specifications, please provide your specific operational requirements.

Our Manufacturing Facility

Standardized processes enhance work efficiency, reduce errors, and boost overall productivity

Optimized work environment fosters positive attitude and sustained team growth

5454 Alloy Tank Trailer Sample

Manufacturing Process

Extruding, Rolling, Machining, Hydraulic Pressure Bulging

Specifications

12790×2500×3900mm

Lighter weight with increased volume capacity for improved fuel efficiency

Reduced CO₂ emissions and environmental impact

Single-piece extrusion profile provides higher overall strength and low center of gravity

Excellent corrosion resistance and safety performance

High material recovery rate with low maintenance costs

Specifications Comparison

Specification/Model	Aluminum Tank Trailer	Same Level Steel Structure Trailer
Weight	6.5T	11.2T
Material Recovery	100%	85%
Fuel Consumption/100km	30L	35L

Factory Equipment

Code	Name	Brand
a	Aluminum ingot melting furnace	GAUTSCHI (Switzerland)
b	2800mm width single stand cold rolling mill	SMS Group (Germany)
c	4 continuous hot rolling mills	SMS Group (Germany)
d	Heavy crop and dividing shear	SMS Group (Germany)
e	Coil material annealing furnace	SMS Group (Germany)
f	All automatic three-dimensional elevated warehouse	Dematic (USA)

Ocean Shipping Process

Flat Rack Container Shipping for Oversized Sheets

Secure fastening of aluminum plates to flat rack containers

Complete waterproof tarp coverage for protection against seawater and rain

Low, evenly distributed center of gravity to prevent tilting during transit

Key Material Characteristics

Alloy Type: Al-Mg alloy (5xxx series) with 2.4-3.0% Mg and 0.5-1.0% Mn content

Excellent corrosion resistance with medium-high strength properties

Mirror finish achieved through mechanical/electropolishing for enhanced aesthetics and cleanability

Superior weldability compatible with MIG/TIG processes without requiring post-weld heat treatment

Alloy Comparison for Tanker Applications

Property	5454	5083	6061
Strength	Medium (H32: 250-300 MPa)	High (H321: 270-350 MPa)	Medium (T6: 310 MPa)
Corrosion Resistance	Excellent (especially vs. chlorides)	Excellent (marine-grade)	Good (requires anodizing)
Weldability	Excellent	Excellent	Good (PWHT needed)
Cost	Moderate	Moderate	Low
Typical Use	Food/chemical tankers	Ships/pressure vessels	Truck frames

Tanker Truck Applications

Tank Body: 5454-H32 mirror sheet (3-6mm thickness), welded construction without coating

Interior: Mirror polish reduces liquid retention and meets sanitary standards

End-Use: Food transport (dairy, edible oils) and mild chemical applications (pH-neutral)

Manufacturing Process

Cylindrical Shell Rolling → Head (End Cap) Forming → Baffle Fabrication → Welding & Joining → Assembly
