Name: Al Mg Alloy EN AW 5754 Aluminium Alloy Plate Sheet Automotive Body Panel
Brand: Qingdao Jero Steel Co., Ltd.
SKU: JA78
Price: 3,000.00 USD
Availability: InStock

Home > Products > Aluminum Alloy Sheet >

Al Mg Alloy EN AW 5754 Aluminium Alloy Plate Sheet Automotive Body Panel

EN AW 5754 aluminium alloy plate

automotive body panel aluminium sheet

5754 Aluminum Plate Sheet

Place of Origin:

CHINA

Brand Name:

JERO

Certification:

IATF 16949 CE ISO IRIS EN 45545

Model Number:

JA78

Chat Now

Request A Quote

Product Details

Type:

Aluminum Alloy Plate

Alloy:

EN AW 5754

Application:

Dashboard Bracket

Thickness:

4-15 Mm

Trade Terms:

CIF, CNF, FOB, EXW

Highlight:

EN AW 5754 aluminium alloy plate

automotive body panel aluminium sheet

5754 Aluminum Plate Sheet

Payment & Shipping Terms

Minimum Order Quantity

7 tons

Price

2800-3200USD/TON

Packaging Details

standard export packages

Delivery Time

20-28 working days

Payment Terms

T/T,L/C

Supply Ability

3,000 tons per month

5454 H32 6.35mm Thickness Aluminum Alloy Sheet In Cylindrical Tank Trailer

Chat Now

Prime Quality 6xxx Series 6063 T6 Aluminum Alloy Sheet Medium Strength

Chat Now

6xxx Series 6082 Aluminum Alloy Sheet 6mm Thick

Chat Now

6000 Series 6062 T6 Aluminium Alloy Sheet Metal 6mm Chinese supplier

Chat Now

86-0532-8787-6524

sales@jero-steel.com

86-0532-8787-6520

Chat Now

Product Description

EN AW 5754 Aluminium Alloy Plate for Automotive Body Panels

Al Mg Alloy EN AW 5754 aluminum alloy plate is specifically engineered for automotive body panel applications, offering exceptional strength, formability, and corrosion resistance.

Product Specifications

Attribute	Value
Type	Aluminum alloy plate
Alloy	EN AW 5754
Application	Dashboard bracket
Thickness	4-15 mm
Trade terms	CIF, CNF, FOB, EXW

Product Overview

5754 alloy is a non-heat-treatable aluminum-magnesium alloy widely used in automotive production, particularly for body panels and structural components. It provides an excellent balance of strength, formability, and corrosion resistance.

Manufacturing Capabilities

Streamlined and standardized workflows for efficient production
Optimized work environment fostering productivity and team cohesion
World-leading technology and equipment for aluminum plate production
Specialization in large size and mass production capabilities

Advanced Production Equipment

Code	Name	Brand
a	Aluminum ingot melting furnace	GAUTSCHI (Switzerland)
b	2800mm width single stand cold rolling mill	SMS Group (Germany)
c	4 continuous hot rolling mills	SMS Group (Germany)
d	Heavy crop and dividing shear	SMS Group (Germany)
e	Coil material annealing furnace	SMS Group (Germany)
f	All automatic three-dimensional elevated warehouse	Dematic (USA)

Technical Specifications

For automotive body panel applications, the most common tempers for 5754 aluminum are:

H22: 1/4 hard - Offers good formability with moderate strength
H24: 1/2 hard - The most typical temper providing optimal balance of strength and formability, ideal for stamping parts like doors, hoods, and fenders

Material Characteristics

Material Composition: Al-Mg alloy (2.6-3.6% Mg), non-heat-treatable (strengthened by cold working)
Corrosion resistance: Superior to 6xxx series (no intergranular corrosion risk), ideal for humid/salty environments
Weldability: Excellent (MIG/TIG welding retains >90% strength)

Mechanical Properties

Temper	Tensile Strength (MPa)	Yield Strength (MPa)	Elongation (%)
O	220-260	80-120	≥15
H32	270-320	150-200	≥10

Comparative Analysis

Process Stage	5754 (Al-Mg)	6061 (Al-Mg-Si)
Formability	Excellent	Requires annealing
Weldability	Superior (no cracking)	Needs PWHT
Surface Treatment	Lower cost	Moderate cost
Weight Reduction	60%+ vs steel	60%+ vs steel

European Market Preference for 5754

Higher Magnesium Content (~3% Mg vs. 5052's 2.2-2.8%) provides better corrosion resistance
Compliance with strict EU environmental standards
Superior weld integrity with less cracking risk than 5052 in critical joints
