Name: High Strength Marine Grade Aluminum Plate 5083 For Ship Hull Plate
Brand: Qingdao Jero Steel Co., Ltd.
SKU: JA52
Price: 3,000.00 USD
Availability: InStock

Home > Products > Aluminum Plate 5083 >

High Strength Marine Grade Aluminum Plate 5083 For Ship Hull Plate

High Strength Aluminum Plate 5083

Marine Grade Aluminum Plate 5083

Marine Grade 5083 Aluminium Plate

Place of Origin:

CHINA

Brand Name:

JERO

Certification:

ABS CCS BV DNV LR IRIS IATF 16949

Model Number:

JA52

Chat Now

Request A Quote

Product Details

Type:

Aluminum Plate 5083

Alloy:

5083

Width:

800-4300mm

Length:

1000mm-38000mm

Application:

Ship Hull Plate

Trade Terms:

FOB, EXW, CFR, CIF Etc

Highlight:

High Strength Aluminum Plate 5083

Marine Grade Aluminum Plate 5083

Marine Grade 5083 Aluminium Plate

Payment & Shipping Terms

Minimum Order Quantity

8 TONS

Price

2800-3200USD/TON

Packaging Details

STANDARD EXPORT PACKAGES

Delivery Time

20-35 DAYS

Payment Terms

T/T,Western Union,MoneyGram,L/C

Supply Ability

3300 TONS PER MONTH

ASTM B209 5083 Aluminum Coil , Aluminum Coil Stock For Transportation

Chat Now

High Strength 10mm Aluminum Plate 5083 Aluminum Sheet For Shipbuilding Industry

Chat Now

EN AW 5083 Aluminum Alloy Plate High Strengh For Metro Vehicle Floor

Chat Now

High Strengh Metal Aluminum Sheet 5083 H321 Aluminum Plate For Tanker

Chat Now

86-0532-8787-6524

sales@jero-steel.com

86-0532-8787-6520

Chat Now

Product Description

High Strength Marine Grade Aluminum Plate 5083 For Ship Hull Plate

High Strength Marine Grade 5083 Aluminum Alloy For Ship Hull Plate

5083 aluminum remains a top choice for ship hulls due to its marine-grade durability, weldability, and lightweight properties.

Typical Thickness Specifications

Thin plates: 3-6 mm (small boats, non-critical areas)
Medium plates: 6-12 mm (most commercial vessels, yachts)
Thick plates: 12-25 mm (large ships, high-stress zones like keels)

Typical Tempers

H116/H321:

H116: Optimized for stress corrosion resistance (ideal for marine environments)
H321: Stabilized after hot rolling, balances strength and corrosion resistance

O (Annealed): Superior formability but lower strength; requires post-weld heat treatment

Physical Properties for 5083 Aluminum Alloy

Property	Value
Density	2650 kg/m³
Melting Point	570°C
Modulus of Elasticity	72 GPa
Electrical Resistivity	0.58 x 10⁻⁶ Ω.m
Thermal Conductivity	121 W/m.K
Thermal Expansion	25 x 10⁻⁶/K

Key Advantages

Superior Cryogenic Performance: Retains high toughness at liquid hydrogen (-253°C) and oxygen (-183°C) temperatures without embrittlement
Fuel Compatibility: Resistant to aviation fuels (e.g., RP-1), hydrazine, and oxidizers (e.g., LOX)
Low-Temperature Toughness: No brittle fracture risk in Arctic/polar applications
Weldability: Compatible with TIG, laser, and friction stir welding (FSW), with weld joint efficiency ≥90%
Fatigue Resistance: Low crack propagation rate under cyclic loading, ideal for reusable spacecraft (e.g., rockets)
